Usage
This wagon is suitable for the transportation of ISO 20, 30, 40, 45 ft long containers and swap bodies.
Want to know more?
Contact one of our Fleetmanagers
Specifications
Tare weight
Approx. 19,0 t
Axle load
22,5 t
Max. load
Approx. 71,0 t
Max speed
120 Km/h
Total length over buffers (LoB)
19.740 mm
Loading length
18.500mm
Loading length (in ft)
60ft
Loading height – top of rail
Max. 1.155mm
Min. Radius Wagon
75 m
Brake blocks
Composite silent break block (C333)
Brake type
2x KE-GP-A (K)
Wheelset type
Ba303
Features
Stay connected
Using our wagons’ telemetrics, Railrelease offer the option to track and trace your wagons at any time. It’s one of the many additional features offered by our online platform, benefiting your fleet management and logistical processes.
Safety first
All our new wagons are being sourced according to the latest safety standards and are being equipped with 25t wheelsets to ensure safety “enroute”.
ECM certified
Our wagons are all ECM certified to guarantee a safe state of running by means of a system of maintenance.
Brakes
All wagons are equipped with K brake blocks. This extends the lifespan of the block and decreases wagon downtime and wheelset wear.
